Unlocking large-scale capabilities and the potential of industries
through high-efficiency bulk production and seamless workflows.
High Throughtput Ideal Size For Footwear / Industrial Parts Intelligent and Reliable High Quality Printed Parts
Powering Large-Scale Production
UBEE MAX

23.7L Maximized Capacity for
High-efficiency Batch Printing

Core Features
Smart Sensor & Control System (SSCS)· Liquid Cooling Empowered System
FSD Module-4 Z-Axis Force Sensor Integrated
Foreign Object Detection
Printing Mechanics Control 		Mask panel Liquid Cooling System
Intelligent Control Systems
Industrial Robot-KK Linear Module Smart Identification System (SIS)
High-Precision Ball Screw
Servo Motor Control System
Ultra-High Rigidity and Longevity 		With NFC and ID Sensing Board Inside
Automated Resin Tank Detection
Automated Build Platform Detection
Functional Prototypes
Foot Wear
Dentistry
Production Manufacturing
Technical Specification
PERFORMANCE
Printing Technology Masked Stereolithography (MSLA)
Build Volume 298 × 166 × 480mm
11.7" × 6.5" × 18.8"
Printing Screen 13.6" 7K
XY Resolution 46μm
Layer Thickness (Z Resolution) 10 - 200μm ( 25, 50, 100μm recommended )
Separation Mechanism Patented low force stereo peeling technology
Micro - stereo composite peeling structures Unit (MPS)
Support Uniz smart support technology

HARDWARE
Dimension / Weight 500 × 480 × 1540 mm [W×H×D]
19.7" × 18.9" × 60.6"
70KG / 154LB
Operating Temperature 18 - 28°C ( 64 - 82°F )
30% - 70%RH
Power Requirement 110V 6A / 220V 3A
60 Hz / 50 Hz
Light Source Matrix LED UV Light Tech
Mechanical Cast Aluminium & CNC, Sheet Metal
Connectivity USB Flash Drive, Wi - Fi, Ethernet
Control Pannel 7" Touch Screen
