SLASH 2

  • A New Generation of Professional Desktop 3D Printers

    8.9" 4K ULTRA HD LCD LIGHT ENGINE

  • A New Generation of Professional Desktop 3D Printers

    8.9" 4K ULTRA HD LCD LIGHT ENGINE

NEW ERA OF INDUSTRIAL 3D PRINTING

Equiped With The Latest 3D Printing Technology, SLASH 2 Delivers Higher Precision, Speed And Reliability Than Ever Before.

METRIC

XY Resolution
49.8μm
Layer Thickness
10-300μm
Build Volume
192×120×200mm

SLASH 2     VS     SLASH PLUS

PRINTING

PRINTING TECHNOLOGY
LCD Stereolithography
LCD Stereolithography
BUILD VOLUME
192 × 120 × 200mm 7.5" × 4.7" × 7.9"
192 × 120 × 200mm 7.5" × 4.7" × 7.9"
XY RESOLUTION
49.8μm
75μm
LCD
Special Designed Long Life-LCD , Optimized Pixel Structure For 3D Printing
Normal LCD
MAXIMUM ACCURACY*
±10μm
±20μm
LAYER THICKNESS
(Z RESOLUTION)
10, 25, 50, 75, 100, 150, 200, 300μm Profile customizable
10, 25, 50, 75, 100, 150, 200, 300μm Profile customizable
SEPARATION MECHANISM
Polymer film natural peel, up to 100x more durable than PDMS
Polymer film natural peel, up to 100x more durable than PDMS
SUPPORT
UNIZ smart support technology
UNIZ smart support technology
PRINTING SPEED
Up to 200 mm/hr
Up to 200 mm/hr
RESIN LEVEL CONTROL
Automatic level control
Automatic level control

DESKTOP SOFTWARE

SYSTEM REQUIREMENT
Windows 7 and up (64-bit only), Mac OS X 10.7 and up (64-bit only), 16GB RAM, OpenGL 2.1, Discrete Graphics
Windows 7 and up (64-bit only), Mac OS X 10.7 and up (64-bit only), 16GB RAM, OpenGL 2.1, Discrete Graphics
ADVANCED FEATURES
Multi-printer management Built-in advanced model repair
Ultra large file support (1GB+)
Multi-printer management Built-in advanced model repair
Ultra large file support (1GB+)
COMPATIBLE FORMAT
STL, OBJ, AMF, 3MF, UNIZ
STL, OBJ, AMF, 3MF, UNIZ

HARDWARE

DIMENSION/WEIGHT
350 × 400 × 530 mm [W×D×H] 14" × 16" × 21", 15KG/31LB
350 × 400 × 530 mm [W×D×H] 14" × 16" × 21", 15KG/31LB
OPERATING TEMPERATURE
Suggested 18–28° C (64–82° F)
Suggested 18–28° C (64–82° F)
POWER REQUIREMENT
100-240VAC, 6A 50/60Hz
100-240VAC, 6A 50/60Hz
OPTICAL SYSTEM
LED array light source with liquid cooling system
LED array light source with liquid cooling system
MECHANICAL
Cast Aluminum & CNC, Injection Molding
Cast Aluminum & CNC, Injection Molding
CONNECTIVITY
USB, Wifi, Ethernet
USB, Wifi, Ethernet

MOBILE APPS

COMPATIBLE SYSTEMS
iPhone, iPad, Android Phone and Tablet
* Maximum accuracy only achievable at integer multiples of smallest pixel sizes.

APPLICATIONS

DENTISTRY

JEWELRY

GARAGE KIT

PRE-ORDER SLASH 2 AND ENHANCE YOUR WORKFLOW

SLASH 2 is now available for preorder. The first SLASH 2 printers are delivered in Q3 2019. Join the queue: printers ordered now will ship in late December 2019.
